PPFD Map Reading: The 20% Drop Rule

A PPFD map is judged by its edges: the 20% drop rule says no grid point should fall more than 20% below the peak reading. Multi-bar fixtures hold about 95% uniformity, a quantum board about 85%, and the inverse-square law does the rest – a 1000-umol/s fixture at 30 cm throws roughly 900 umol/m2/s onto a 2 m2 canopy and only about 225 at 60 cm. This guide reads those maps against the rule before you hang a fixture.

How Light Coverage Architect — Bar vs QB, Inter-Canopy & UV Blueprint Helps You Master This

1. Measure the grow footprint in centimetres and convert to square metres (÷10,000), then set the fixture form-factor, count, emission PPF and mount height.
2. Compute the average canopy PPFD as fixture PPF × count × dim × 0.9 ÷ area, scaled by the inverse-square ratio (30 cm ÷ height)².
3. Read the uniformity from the fixture form — multi-bar ~95%, quantum board ~85% — and lift the floor by the fixture-count overlap.
4. Estimate the lower-canopy hand-off with the deliberate inter-canopy fraction (~40% of top) plus any in-canopy tower flux, and the UV share kept inside the UV-A 0–10% / UV-B 0–2% window.
5. Integrate the daily light integral for your photoperiod, compensating the peak for a sunrise/sunset ramp so the delivered DLI is preserved.
6. Size the thermal and wiring load: driver waste heat = fixture watts × (1 − eff/100), and cross-check the PPFD by dividing a lux reading by the calibration factor (~650).

The Formula Behind the Result

• Average canopy PPFD — fixture photon flux over the footprint, scaled by the inverse-square mount height → overline{PPFD} = frac{N cdot Phi_{ppf} cdot D cdot eta}{A} times left( frac{30}{h} right)^2
• Uniformity — multi-bar fixtures hold the ~95% floor, a quantum board ~85%, with a fixture-count overlap lift → U_{bar} approx 95% quad U_{qb} approx 85% qquad U = min(, U_{fx} + (N-1) cdot 1.5,, 99.5%)
• Coverage area — the footprint your fixtures can hold at the working target PPFD → A_{cover} = frac{N cdot Phi_{ppf} cdot D cdot eta}{PPFD_{target}}
• Inter-canopy PPFD — the lower third receives ~40% of top light; an in-canopy tower adds its own flux → PPFD_{inter} = overline{PPFD} cdot 0.40 ; + ; (text{inter-canopy} , ? , 200 : 0)
• UV contribution — UV share of the run as PPFD, held inside the UV-A and UV-B safety window → PPFD_{UV} = overline{PPFD} cdot frac{UV%}{100} qquad (text{UV-A } 0!-!10%,,; text{UV-B } 0!-!2%)
• Daily light integral — average PPFD over the photoperiod; the dimmed fixture arc averages 2/π of its peak under a sine daylight curve → DLI = overline{PPFD} cdot frac{h_{photo} cdot 3600}{10^6} qquad Phi_{dim} = Phi cdot frac{D}{100} cdot frac{2}{pi}
• Dimming compensation — a sunrise/sunset ramp averages ~50% of peak, so the peak must rise to hold the same DLI → PPFD_{peak} = frac{PPFD_{flat} cdot t_{total}}{t_{total} - 0.5 cdot t_{ramp}} qquad t_{ramp} = t_{dawn} + t_{dusk}
• Driver heat and calibration — rejected watts from driver efficiency, BTU/h, and the lux÷factor PAR-meter hand-off → Q_{driver} = V_{w} cdot (1 - tfrac{eta_{eff}}{100}) qquad Q_{BTU} = Q_{driver} cdot 3.41214 qquad PPFD = frac{lux}{655}

PPFD Map Reading & the 20% Drop Rule: What the Numbers Should Be

• Multi-bar LED fixtures hold a roughly 95% uniformity floor across the footprint; a single quantum board concentrates heat and photons into a center hotspot and settles nearer 85% — the difference is exactly the falloff you see at the edges.
• The inverse-square law rules coverage: double the mount height and the on-target PPFD quarters. At 30 cm a 1000-µmol/s fixture throws ~900 µmol/m²/s onto a 2 m² canopy, at 60 cm only ~225.
• Inter-canopy light is the difference between a top-lit and a volumetrically-lit plant: the lower third sees only about 40% of top-canopy PPFD by Beer-Lambert, and an in-canopy tower is what recovers it.
• UV is a finishing tool, not a main source: hold UV-A near 0–10% and UV-B at 0–2% of the photoperiod in flower only, and ramp it up over days — resin, terpenes and pest defense respond, but stress and bleaching do too.
• Adding a sunrise/sunset ramp carves about half of peak per ramp, so the controller must raise the peak PPFD to keep the same total DLI — the compensation arm returns exactly that peak and its percent increase.

Use the free Climate Controller & HVAC Sizer — VPD, Dehumidifier & CO2 Blueprint to run the numbers on your own setup.

Use the free Nutrient Cost Optimizer — Bulk Mixing & Recycling Blueprint to run the numbers on your own setup.

Use the free Substrate Moisture Calculator — Dryback & Water Holding Blueprint to run the numbers on your own setup.

Compare every free calculator side-by-side on the MistCulture tools hub — each one keeps your workspace in sync.

Related guides

Applying the 20% drop rule to a 2 m2 canopy

The 20% drop rule reads the peak as 100% and flags any grid point more than 20% below it. On a 900 umol/m2/s peak the floor is 720; a multi-bar array at about 95% uniformity keeps every point at 855 or better and a quantum board at about 85% holds 765 or better, so both pass at 30 cm. Double the height to 60 cm and the same 1000-umol/s fixture throws about 225 – a 75% drop that breaks the rule outright.
